15
IP L
AYER
A
PPLICATION
Introduction This chapter provides specific information for the IP Layer application and how it
operates using the TXPORT MultiPro platform and NMCS software.
IP Layer
Description The IP Layer application is the implementation of the IP Layer of the TCP/IP
architecture based on RFC 791. The TXPORT IP Layer supports the Address
Resolution Protocol (ARP RFC 826) and a subset of the Internet Control Message
Protocol (ICMP RFC 792 including ICMP router discovery messages RFC 1256).
The IP Layer is intended to provide communication services to the IP PAD, to the
TCP stack, or to the UDP layer that itself provides communication services to the
SNMP agent.
Configuration
/ Operation
IP Layer
Parameters
The IP Layer parameters screen is accessed from the IP Layer selection on the
Internetworking Applications screen (see Global Parameters on page 60).
Figure 15-1 shows the IP Layer parameters screen.
Each of these parameters is described in the following paragraphs.
TXPORT INTELLINET Configuration Program
Configuration 1000
IP Layer parameters
Line Module [1]
Copy IP Parameters from Configuration [ ] Module [ ]
IP address [ 0].[ 0].[ 0].[ 0]
Sub Net mask [ 0].[ 0].[ 0].[ 0]
Multicast address [224].[ 0].[ 0].[ 1]
Solicitation address [224].[ 0].[ 0].[ 2]
Broadcast address [255].[255].[255].[255]
Max Transmit Unit [ 576] ICMP retry count [ 3]
ARP retry count [ 3] ARP aging timer (s) [ 60]
Re-assembly timer (s) [ 30] Time to live (s) [ 16]
Link layer (Eth) [E]
Delete IP application [ ]
ESC=Main Menu F1=Help F5=Clear F7=Redisplay F8=Jump F9=Previous F10=Next
Figure 15-1 IP Layer Parameters
