Configuring Main System 1
2. Click for the PTZ setup. Refer to step 1 in the section of Object Tracking Setup.
3. Choose the camera screen of the PTZ. For this example, the images of the PTZ camera show in
the camera 2 screen.
4. Use the slide bars of Pan, Tilt and Zoom to set up the View 1 as shown below. Then click the Add
button to apply the settings. The View 1 will show in the upper-left corner of the right screen.
Figure 1-78
5. Click the drop-down menu to set up View 2, 3, and 4, one at a time. Refer to Step 4 for the View 1.
6. Specify Idle Time (sec), indicating the zooming duration in seconds.
Figure 1-79
7. Click the drop-down menu of the Idle Mode item. The seven options included inside are: None,
View 1, View 2, View 3, View 4, Tracking and Refresh View.
„ None: After zooming, the PTZ camera will remain on the same view until the next zooming
command.
„ Tracking: After the idle time, the PTZ camera will start tracking if it is also being applied for
the tracking function.
„ View 1,2,3,4: After the idle time, the PTZ camera will go back to the preset View 1, 2, 3, or 4.
„
Refresh View: After the idle time, the 4 views will be refreshed.
8. Click Test to check your settings. Use the mouse to outline a desired area in one of the four views.
The area will be magnified in the left screen.
9. Click OK to apply the displayed selections and close the window.
81
