I /O Applications 2
Quick Link
The Quick Link provides a quick access to triggered I/O devices. It is a separate window to display all
group icons. The group icon flashes when any included I/O device is triggered. Clicking the flashing
icon will bring you to the I/O location in the Advanced I/O List.
¾ To open the Quick Link window, click the Toggle Quick Link button. (No. 3, Figure 2-13).
¾ To set the Quick Link window at panel startup, see the Show Quick Link option in Figure 2-18.
Figure 2-22
Forcing Output
To manually force an output, click one output, and select Force Output.
¾ In the Standard I/O List, you can force the output individually.
¾ In the Advanced I/O List, considering cascade triggers, you can only manually force the output at
the top level, e.g. Figure 2-23. Other outputs at sub levels cannot be forced manually, e.g. Figure
2-24.
However, if the output is not in a cascading hierarchy, you can definitely force it manually, e.g.
Figure 2-25.
Figure 2-23 Figure 2-24 Figure 2-25
149
