Point-of-Sale (POS) Application
3
POS Data Sender
To attach the graphic-mode POS system with the Windows operation system and serial output to
GV-System, follow these steps:
1. Connect the POS system as illustrated below.
GV-System + USB dongle
Windows-based and built-in serial-port
POS System
Printer
Cross-over RS232
RS232 or Parallel
2. Insert the Surveillance System Software CD to the POS system. It will run automatically, and a
window appears.
3. Select
the
Install V 8.2.0.0 System.
4. Select
the
Software POS Driver (Only for Graphic mode POS System), and follow on-screen
instructions to complete the installation.
5. Go
to
Windows Start, point to Programs, select DVR-POS, and then click DVR POS Driver. The
following window appears.
Figure 3-1 POS Data Sender
6. Click
Start Service, and then select the COM port to send graphic data to the GV-System.
Note: The GV-System must be configured and ready for this application. To set up the GV-System,
see Setting a POS System below.
159
