Viewing Live Video Using WebCam 6
FTP Server Settings
The option of FTP transfer JPEG file allows you to access the recording files in a folder tree at a client
computer installed with the FTP server. In Figure 6-6, select the FTP transfer JPEG file option, and
then click the FTP Setup button to display the following dialog box.
Figure 6-13 FTP Setup
1. In the Server Host Name field, enter the IP address or domain name of the FTP server. Keep the
port setting as default at 21.
2. Enter a valid user name and password to access the FTP server.
3. Specify a file path to save the recording files on the FTP server.
4. Click the Transfer Camera button and assign which camera’s files to be transferred to the FTP
server.
5. In the Send File Delay field, specify the time of updating JPEG files from the GV-System to the
FTP server. The time range is from 0.1 to 10 sec.
6. In the Connection Retries field, specify the number of retries when the FTP connection fails (Max:
999). In the Retry Delay field, specify the interval between each retries (Max: 9999 sec.).
7. Click OK to apply above settings.
255
