Configuring Main System 1
24
DSP Spot Monitor Controller
The Controller integrates the GV-DSP Card with spot monitor (TV monitor) applications. It allows
screen divisions on the spot monitor differently from the main screen.
With the Controller, you can also define the channel sequence of the display screen and adjust video
images on the spot monitor.
Note: The GV-DSP-100 Card doesn’t support this feature.
85
Spot Monitor Controller
To open the Spot Monitor Controller, follow these steps:
1. Click the Configure button (No. 14, Figure 1-2), point to Accessories, select DSP Spot Monitor,
and then select Spot Monitor Setup. This dialog box appears.
Figure 1-102
2. Check Use DSP as Spot Monitor at next Startup, and click OK.
3. Restart the GV-System.
4. Click the Configure button (No. 14, Figure 1-2), point to Accessories, select DSP Spot Monitor,
and then select Spot Monitor Controller. The Spot Monitor Control window appears.
Note: When the DSP Spot Monitor Control feature is enabled, DSP Overlay will be disabled in the
Main System.
103
