Note:

1. The

Enable Directdraw Overlay and De-interlace Render features can greatly enhance image

quality. If your VGA card supports DirectX9, enable both settings.

2. You may see a warning message “Directdraw Create Overlay Failed” when trying to use

WebCam Remote Control to connect to a server. The message indicates the server has the

Enable Directdraw Overlay feature enabled. It only means the remote side will not see the

images with DirectDraw applied. It is safe to press YES to continue the connection.

Tip: To check the version of your DirectX, search for the file name dxdiag. Open the file and find the

related information. DirectX 9.0c is also included in the Surveillance System Software CD.

Startup Auto Login: Select and press the Arrow button to assign an ID used at system auto

startup. After the setup, the system will automatically login using this ID at next startup, without

asking for ID and Password. For related settings, see Launching GV-System from System Tray

later in this chapter.

Panel Resolution: Select the resolution from the drop-down list that best fits your computer

monitor screen.

Mini-View for Remote Desktop: Squeezes all video channels into a single 320x240 view. Since

you may use Microsoft Remote Desktop (a feature that comes with Windows XP Professional

Edition) to set up the Main System through network, it is important to get smallest size possible

data to transfer over network.

1. Click

the

Configure button (No.14, Figure 1-2), point to General Setting, and then select

System Configure.

2. In the System Configure dialog box, select Mini-View for Remote Desktop in the Startup

section, and then click OK to apply the setting.

3. Restart the Main System.

4. To switch between the mini and normal view, click the Configure button (No.14, Figure 1-2),

point to A/V Setting and select Mini-View Switch.
