Configuring Main System 1
Note: Each dome will need to be addressed correctly. Refer to the dome manufacturers’
documentation for details.
65
Auto Switching PTZ Control Panels
The function allows the corresponding PTZ control panels to be called up automatically when you
switch to different PTZ camera screens. To enable the function, follow the steps below:
1. Click the Configure button (No. 14, Figure 1-2), point to General Setting, and then select
System Configure to display the System Configure window.
2. In the PTZ Control section, click the Arrow button, point to PTZ Panel Switch and click Auto.
Figure 1-53
3. When the Camera Mapping Setup window appears, specify the brand name and hardware
address of each PTZ camera. Then click OK for the application.
59
