Playing Back Video Files 4
[Bandwidth Control] Check to prevent overloading on slow network. You can set the bandwidth from
0 to 100,000 Kbytes to transfer in one second.
[Enhance network security] Enable to enhance Internet security. Please note when the feature is
enabled, the subscribers using earlier version than 7.0 cannot access the RPB any more.
Working with Remote Playback Client at the Client PC
RPB Client software is to be installed at the client PC, and the software is included in the Surveillance
System Software CD. Install and execute Remote Playback Client Site.
Camera views from different servers may be displayed in a single 16-channel screen view. Clicking the
Page Select button turns the screen view to the next page. Maximum two pages (total 32 channels)
may be displayed in one RPB Client.
9
8
6
11
10
12
4
3
5
7
15 14 16 17 13
1 2
Figure 4-38
215
