Viewing Live Video Using WebCam 6
Single View MPEG4 Encoder Viewer
1 2 4
8
10 11 12
5
6
7
13 14 15
16
9
3
Figure 6-17 Single View MPEG4 Encoder Viewer
The controls in the Single View Viewer:
No. Name Description
1 Countdown Timer
Indicates the remaining time when you log in as Guest. When the time
is up, you will be logged out automatically.
2 Menu
Includes these options: Information, Video, Audio, Preset Go, I/O
Control, Alarm Notify, Camera Adjustment and Download. For details,
see Control Panel later in this chapter.
3 Expand / Close Expands or closes the Menu option list.
4 Option Selection Bar Selects the Menu option. For the list of options, see “Menu” above.
5 Show System Menu
Brings up these options: Alarm Notify, Video and Audio Configuration,
Remote Config, Change Server, Show Camera Name and Image
Enhance.
6 Change Camera Sets the desired camera for display.
7 PTZ Control Displays the PTZ control panel.
8 I/O Control Displays the I/O control panel.
9 Full Screen Switches to full screen view.
10 File Save
Saves live video in the local computer. Use the slide bar to adjust the
time length of each saved clip.
11 Change Quality
Adjusts video quality with two options: Geo H264 and Geo MPEG4. If
the connected site (GV-2004, GV-2008, GV-IP Camera, or GV-Video
259
