Live Viewing Using Remote Applications
8
327
3. In the MultiCam Remote Viewer, click the Connect button and select Internet/Intranet_TCP/IP to
bring up the following dialog box:
Figure 8-2
4. In the IP Address field, type the IP address or domain name of the system you wish to connect to.
The field memorizes 10 most recently used addresses.
5. Type in port number in Port field. Use default value if you are not sure what to enter for this field.
6. Enter a valid user ID and password and then click the Login button. Video stream should appear
when connection succeeds, as shown:
Figure 8-3
Functions of toolbar buttons are listed in following table:
Button
Description
Connect
Selects modem dial-up or TCP/IP connection.
My Favorite
Adds to My Favorite
Stop Terminates
network
connection
Zoom In
Enlarges video.
Zoom Out
Shrinks video.
Lock
Locks a particular camera.
Preferences
Brings up the preferences setting window.
