CCTV Camera Pros Geovision 8.2 Multicam Digital Surveillance System - Manual (Page 315)

Viewing Live Video Using WebCam 6
Viewing and Controlling I/O Devices
To view and control the connected I/O devices, select the desired camera and click the button
(Figure 6-58).
[I/O Monitoring Setting / Monitoring]
Figure 6-60
The number on the toolbar indicates the connected module. To view and control the input and output
devices, click the number button.
[I/O Setting]
Figure 6-61
“I”: displays the status of triggered input devices. See Figure 6-60.
“O”: displays the connected output devices. See Figure 6-61.
301
