Setting Up PTZ IP Camera
To set up the IP camera with PTZ functions, follow these steps:
1. To add the PTZ IP camera to the system, follow the steps in Adding IP Video Sources above.
2. To enable the PTZ function, click the Configure button (No. 14, Figure 1-2), point to General
Setting and select System Configure. The System Configure dialog box appears.
3. In the PTZ Control section, enable PTZ Device Setup and select the PTZ IP camera from the
drop-down list.
4. Click OK and return to the main screen. Now you should see PTZ Control button displayed on the
right side of the main screen. Click this button to display the onscreen control panel.
For details on using the control panel, see PTZ Control Panel earlier in this chapter.
