E-Map Application 7
Starting E-Map
After creating an E-Map file, go to the Main System. Click the ViewLog button and then select E-Map
to display the following E-Map Viewer window. Double-click any E-Map file of the local host to open it.
Note: If you have created the E-Map files for remote hosts , these files will also be displayed in the
E-Map Viewer window but won’t function here. They only work on WebCam that is discussed later.
1 2
3 4 5 6
Figure 7-4 The E-Map Viewer Window
The controls in the E-Map Viewer window:
No. Name Description
1 Popup Settings Selects desired cameras and I/O devices for the pop-up map function.
2 Toggle Popup Toggles between popup and non-popup function.
3 Tree View The tree view of E-Map files and folders.
4 Flashing Icon The flashing icon represents a triggered camera or an I/O device.
5 Output Icon Manually forces an output device.
6 Camera/Dome Icon Views the live video associated with that camera/dome.
315
