Point-of-Sale (POS) Application
3
Printer Type: Select Serial Port, Parallel Port or TCP/IP Port that the POS system belongs
to.
For TCP/IP Port applications, see GV-Data Capture V3 Series User’s Manual.
Device: Assign the POS system to a camera screen. POS 1 displays the images and data on
the Camera 1 screen; POS 2 on the Camera 2 screen, and so on. Click the […] button next to
the item to rename the device.
POS Module: Select the printer attached to the POS system. If it’s not Epson, select General
for other brands. If the printing is in the graphic mode, select GraphMode.
For Graphic mode applications, see the POS System Connection section above.
COM Port: Select the COM port that the POS system is connected to.
The parameter button: Click the button to configure Baud Rate, Data Bits, Parity, and/or
Stop Bits to match those of the POS system, or keep them as defaults.
Cash Drawer Open Signal: This option is only available when an input module is configured
in the Main System. Assign the input module connected to the cash drawer. Every time when
the cash drawer is opened, a signal will be sent to the Main System and recorded in System
Log for later retrieval.
Use Codepage Mapping: This feature is to support special characters and symbols display.
For details, see Codepage Mapping.
Trace Mode: Check this item only after getting the recommendation from our technical
support staff.
3. After above settings, click Add to add the POS system to the Main System.
