274
The controls in the Multi View:
No. Name Description
1 Monitoring Window Displays live video.
2 Host Server
Displays connected GV-Systems and their available
cameras.
3 UPnP Device Displays all hosts on the same LAN.
4 PTZ Control Displays the PTZ control panel.
5 I/O Control Displays the I/O control panel.
6 Channel Status Indicates the general information of the selected channel.
7 ViewLog
Plays back recorded files of the remote GV-System by using
the video player ViewLog.
8 Configure Accesses system settings of the Multi View.
9 Edit Host Adds, deletes or modifies GV-Systems.
10 Camera Status Displays the camera status of the connected GV-Systems.
11 Host Information
Displays the general information of the connected
GV-Systems.
12 Zoom in and out Zooms in or out the selected channel.
13 Add/Remove Channel
Adds or deletes the channels for video polling. Click the Add
or Remove Channel button and then click the desired
channel to add to or remove from the video polling.
14 Full Screen Switches to a full screen view.
15 Video Polling Rotates through the selected channels.
16 Screen Divisions Sets screen divisions to 4, 8 or 16.
17 Exit/Minimize Closes or minimizes the Multi View window.
18 Speaker Enables live audio from a remote GV-System.
19 Microphone Enables speaking to a remote GV-System.
20 Play Establishes the connection to a GV-System.
21 Stop Terminates the connection to a GV-System.
22 Save Saves live video.
23 Quality Changes video resolution.
24 Snapshot Takes a snapshot of the selected channel.
25 Save Camera to Multiple Host Saves the selected cameras and to create a Multiple Host.
