Viewing Element Topology and Properties
266
NOTE:
Right-click menu options are not available to undiscovered fabrics.
Table 31
Menu Options Accessible from the Topology*
Menu Option
Description
Go to Navigation
Details
This menu option redirects you to the Navigation page. If the element is
labeled discovered, you are shown the Properties page. Elements are labeled
discovered when the management server has discovered the element but
cannot obtain additional information about it. See ”
Go to Element
Topology
Displays a graphical representation of the path of an element. This also
includes multipathing. See ”
Show Events
Displays the events for an element. See ”
Show Policies
Displays the Policy tab for the element. You can then view, add, modify, and
delete polices assigned to the element. See ”
page 324 for more information.
Update Element
Data
The management server gathers new and changed details from the element
and then redraws the topology with the updated information.
The Update Element Data functionality does not detect element components
that have been removed, such as ports and LUNs. For example, assume you
removed several LUNs from an array. If you right-click the storage system and
select Update Element Data, the LUNs still appear in the user interface. You
must perform Discovery Data Collection for the deleted LUNs to be removed
from the user interface. See ”
Show Impact
Highlights the elements that are impacted. See ”
Show Cluster
Impact
Highlights the elements that are impacted. See ”
Show Port Details
Lets you determine the use of each port for all elements in the network. See
” on page 280 for more information.
Build/Edit Cluster
Lets you manually build or edit host and application clusters. See ”
