Icons Displayed in the Topology
Table 30 on page 255 provides a brief description of the icons displayed in the System Manager
topology.
Displays the event severity icons for the elements displayed in
the topology.
See ”
Viewing Event Status in the Topology ” on page 284. This
feature is disabled for Performance Manager and Capacity
Manager.
Calculates the topology paths. Clicking this button also allows
you to view direct attached storage in System Manager. Direct
attached storage is indicated by dotted lines. If any of the paths
are not fully calculated, a pop-up window displays a list of all
the hosts with partially calculated paths.
Displays the backup topology. The backup topology is also
displayed in Backup Manager.
See ”
About Backup Manager ” on page 571 for more
information about the backup protection provided in this
product.
Table 29 Feature of the Toolbar in System Manager (continued)
Button Description
Table 30 Icons Displayed in the Topology
Icon Description
Indicates an application.
Indicates a file server.
Indicates a host. This particular icon is for a host running
Microsoft Windows.
Indicates a storage system.
