QPC841 Quad Serial Data Interface card
Table 417
QSDI card baud rate switch settings (cont’d.)
Port 1 – SW10
Port 2 – SW11
Port 3 – SW12
Port 4 – SW13
Baud
rate
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
4800
off
on
off
off
off
on
off
off
off
on
off
off
off
on
off
off
9600
off
off
off
off
off
off
off
off
off
off
off
off
off
off
off
off
DTE/DCE mode switch settings
Table 418 "QSDI card DTE/DCE mode switch settings" (page 992)
shows
the DTE/DCE mode selection switches for the four serial ports.
Table 418
QSDI card DTE/DCE mode switch settings
Port 1 – SW8
Port1 – SW9
Mode
1
2
3
4
5
6
1
2
3
4
5
6
DTE (Terminal)
on
on
on
on
on
on
off
off
off
off
off
off
DCE (Modem)
off
off
off
off
off
off
on
on
on
on
on
on
Port 2 – SW6
Port 2 – SW7
Mode
1
2
3
4
5
6
1
2
3
4
5
6
DTE (Terminal)
on
on
on
on
on
on
off
off
off
off
off
off
DCE (Modem)
off
off
off
off
off
off
on
on
on
on
on
on
Port 3 – SW4
Port 3 – SW5
Mode
1
2
3
4
5
6
1
2
3
4
5
6
DTE (Terminal)
on
on
on
on
on
on
off
off
off
off
off
off
DCE (Modem)
off
off
off
off
off
off
on
on
on
on
on
on
Port 4 – SW2
Port 4 – SW3
Mode
1
2
3
4
5
6
1
2
3
4
5
6
DTE (Terminal)
on
on
on
on
on
on
off
off
off
off
off
off
DCE (Modem)
off
off
off
off
off
off
on
on
on
on
on
on
Test switch setting
Switch SW16 is only used for factory testing; all of its switches must be set
to OFF for proper operation.
