Configuration

911

Table 390
LD 14 - Trunk Data Block for NTCK16AX. (cont’d.)

Prompt

Response

Description

BTID
(See

"page 803" (page 911)

Enter the country busy tone ID:

Tortola, Brazil = 10
Mexico = 10 or 08 (depending on CO)
Singapore = 11
Ireland = 3 or 9 (depending on CO)
Chile, Venezuela, Thailand, Korea =
06. Argentina = 12 or 07, Turkey = 14

SUPN

(NO) YES

Supervision yes (no)

STYP

BTS

Busy tone supervision enabled

BAT

Loop break supervision enabled

CLS

(LOL) SHL

Attenuation Pads In, (Out)

DTN, (DIP)

Digitone signaling, (digipulse)

P20, P12, (P10)

Make-break ratio for pulse dialing
speed.

Note:

These prompts are required only for the first unit defined on each

NTCK16AX card.PPIDFreqMin pulse detection
0316Kz>70ms
0412Kz>70msCountryBTIDCadence
Brazil, Tortola10250 ms +/- 50 ms on/off
Mexico10250 ms +/- 50 ms on/off
Mexico 8375 ms on/off
Singapore11750 ms on/off
Ireland 3500 +/- 50 ms on/off
Ireland 9375 - 750 ms on/off
Kuwait, Chile 6500 +/- 50 ms on/off
Venezuela, Indonesia12300 ms on, 200 ms off
Thailand, Korea12300 ms on, 200 ms off
Argentina12300 ms on, 200 ms off
Argentina07250 - 500 ms on/off
Turkey1410 seconds of Tone 1:

200 ms off, 200 ms on; 200 ms off,
200 ms on; 200 ms off, 200 ms on;
200 ms off, 600 ms on; followed by

Tone 2: 200 ms off, 200 ms on.

NTCK16BX Central Office trunk card

Route Data Block

Respond to the prompts in LD 16 as shown:
