90 Option settings
Table 27
NT6D80 Multi-purpose Serial Data Link card (cont’d.)
RS-232-D DTE or DCE*
RS-422-A DTE
RS-422-A DCE all off
all off
all on all off
all on
all off
* RS-232-D DTE and DCE modes are software configured. RS-422-A DTE and DEC modes are
switch configured.
Note: The device number for the MSDL card is configured in LD17 at the prompt DNUM. You must
also set the device number, using switches S9 and S10, on the MSDL card. S9 designates ones
and S10 designates tens. To set the device number as 14, for example, set S10 to 1 and S9 to 4.
NT8D14 Universal Trunk card
Table 28 "NT8D14 vintage AA jumper strap settings" (page 90) through
Table 32 "NT8D14 vintages BA/BB cable loop resistance and loss" (page
92)
list option settings for the NT8D14 Universal Trunk card.
Table 28
NT8D14 vintage AA jumper strap settings
Modes Location Jumper strap
Central Office (CO) J1, J2 off
2-way tie trunk (loop dial repeat) J1, J2 off
2-way tie trunk (outgoing/incoming dial) J1, J2 off
Recorded announcement (RAN) J1, J2 off
Paging trunk J1, J2 off
Japan CO/DID operation J1, J2 off
DID operation: loop length > = 2000 3 /
4
J1, J2 on
DID operation: loop length < 2000 3 /
4
J1, J2 off
Note 1: off = no strap present.
Note 2: Locations (J1, J2) apply to all eight units.
Table 29
NT8D14 vintages BA/BB jumper strap settings-factory standard
Jumper strap settings
Trunk types Loop length J1.X J2.X J3.X J4.X
CO/FX/WATS
2-way tie (LDR)
2-way tie (OAID)
Zero–1524 m (5000 ft)
DID Zero–600 ohms
Off Off 1–2 1–2
