892 NTBK51 Downloadable D-channel Handler daughterboard
The NTBK51 daughterboard, when installed on the NTAK09 digital trunk
card, is addressed in the same slot as the NTAK09.
One NTBK51 daughterboard is required for each PRI link.
LEDs are located on the faceplate of the NTAK09/NTBK50 card. The
DCHI LED is a dual-color (red/green). The LED is described in
Table 385
"Faceplate LED" (page 892) .
Table 385
Faceplate LED
State Definition
On (Red) NTBK51 is disabled.
On (Green) NTBK51 is enabled, but not necessarily established.
Off NTBK51 is not equipped.
Functional description
The main functional blocks of the NTBK51 architecture include the
following:
• Microprocessors
• Main memory
•
Shared memory
•
EPROM memory
• Flash EPROM memory
• EEPROM memory
•
Serial communication controller
• Sanity timer
• Bus timer
The main functional blocks of the NTBK51 architecture include the
following:
• Microprocessors
• Main memory
•
Shared memory
•
EPROM memory
• Flash EPROM memory
• EEPROM memory
