Option settings
Table 42
QPC441 3PE card installed in the NT4N41CP PII Core Net modules (cont’d.)
Group 0
off
on
on
off
on
on
on
on
Group 1
off
on
on
off
on
on
off
on
Group 2
off
on
on
off
on
off
on
on
Group 3
off
on
on
off
on
off
off
on
Group 4
off
on
on
off
off
on
on
on
Group 5
off
on
on
off
off
on
off
on
Group 6
off
on
on
off
off
off
on
on
Core/Net 0
(Shelf 0)
Group 7
off
on
on
off
off
off
off
on
Group 0
off
on
on
off
on
on
on
off
Group 1
off
on
on
off
on
on
off
off
Group 2
off
on
on
off
on
off
on
off
Group 3
off
on
on
off
on
off
off
off
Group 4
off
on
on
off
off
on
on
off
Group 5
off
on
on
off
off
on
off
off
Group 6
off
on
on
off
off
off
on
off
Core/Net 1
(Shelf 1)
Group 7
off
on
on
off
off
off
off
off
Table 43
QPC441 3PE card installed in the NT5D21 modules
Jumper Settings: Set Jumper RN27 at E35 to "A".
Switch Settings
Module
D20 switch position
1
2
3
4
5
6
7
8
NT5D21 (Option 61C)
Core/Network 0
off
on
on
off
on
on
on
on
Core/Network 1
off
on
on
off
on
on
on
off
NT5D21 (Option 81C)
