Media Gateway Controller card 947
•
A system with only DSP daughterboards.
• A system with both DSP daughterboards and Media Cards.
The DB-96 is supported only in expansion site #1 on the MGC card. If
a DB-96 is detected in expansion site #2 during bootup, an installation
error message is displayed on the MGC faceplate. The installation
error message remains on the MGC faceplate display until the DB-96 is
removed from expansion site #2. The DB-96 installation error message
can be cycled through with other error messages. The DB-32 is supported
in both expansion sites on the MGC card.
There are five possible DSP daughterboard configurations for both Call
Server or Media Gateway configurations (3) and (4):
• A DB-32 in DB expansion site #1.
•
A DB-32 in DB expansion site #2.
•
A DB-32 in DB expansion site #1 and a DB-32 in DB expansion site
#2.
• A DB-96 in DB expansion site #1.
• A DB-96 in DB expansion site #1 and a DB-32 in DB expansion site
#2.
The following table summarizes the supported placement of the DBs in the
MGC expansion sites and the card slots represented by each DB.
Table 401
DSP daughterboard placement
DB Size DB Position #1 DB Position
#2 Card Slot
0 Card Slot
11 Card Slot
12 Card Slot
13
DB-32 Yes Yes Yes Yes No No
DB-96 Yes No No Yes Yes Yes
A DSP DB-32 installed in expansion site #1 represents card slot 11. A
DSP DB-32 installed in expansion site #2 represents card slot 0. A DSP
DB-96 installed in expansion site #1 represents card slots 11, 12 and 13.
