NT8D02 and NTDK16 Digital Line cards

Table 181
NT8D02 Digital Line Card - backplane pinouts (cont’d.)

Backplane

Pinout*

Lead

Designations

Backplane

Pinout*

Lead

Designations

68A

Line 14, Ring

68B

Line 14, Tip

69A

Line 15, Ring

69B

Line 15, Tip

*These pinouts apply to both the NT8D37 and NT8D11 backplanes

Configuration

This section outlines the procedures for configuring the switches and
jumpers on the NT8D02 Digital Line card and configuring the system
software to properly recognize the card.

Figure 114 "Digital line card -

jumper block and switch locations" (page 444)

shows where the switches

and jumper blocks are located on this board.

This section outlines the procedures for configuring the switches and
jumpers on the NT8D02 Digital Line Card and configuring the system
software to properly recognize the card.

Figure 115 "Digital line card -

jumper block and switch locations" (page 445)

shows where the switches

and jumper blocks are located on this board.

This section outlines the procedures for configuring the switches and
jumpers on the NT8D02 Digital Line Card and configuring the system
software to properly recognize the card.

Figure 116 "NT8D02 Digital Line

Card - jumper block and switch locations" (page 446)

shows where the

switches and jumper blocks are located on this board.

Jumper and switch settings

The NT8D02 Digital Line card has no user-configurable jumpers or
switches. The card derives its address from its position in the backplane
and reports that information back to the Call Server through the LAN Link
interface.

The NT8D02 Digital Line Card has no user-configurable jumpers or
switches. The card derives its address from its position in the backplane
and reports that information back to the Meridian 1 CP through the LAN
Link interface.
