Physical description 855
The NTAK93 daughterboard provides the following features and functions:
• D-channel interface or DPNSS interface
• Special features included for LAPD implementation at DCH:
— system parameters are service changeable (system parameters
are downloaded from software)
— incoming Layer 3 message validation procedures are implemented
in the D-PORT firmware
— supported message units and information elements can be service
changed
— translation of the CCITT message types information elements into a
proprietary coding scheme for faster CPU operation
— convention of IA5-encoded digits to BCD-encoded digits for
incoming Layer 3 messages for faster CPU operation
— self-test
— loopback
Physical description
The DCH function can be installed in the main and IP expansion cabinets.
The DTI/PRI card which carries a DCH daughterboard resides in the main
and IP expansion cabinets.
The DCH function can be located in the main and IP expansion cabinets.
The DTI/PRI card which carries a DCH daughterboard resides in the main
and IP expansion cabinets.
Faceplate LEDs
NTAK09 1.5 Mb PRI and NTBK50 2.0 MB PRI cards
LEDs are located on the faceplate of the NTAK09 and NTBK50 cards. The
DCHI LED is dual-color (red and green). The LEDs are described in
Table
364 "Faceplate LEDs" (page 855) .
Table 364
Faceplate LEDs
State Definition
On (Red) NTAK93 is equipped and disabled.
On (Green) NTAK93 is equipped and enabled, but not necessarily
established.
Off NTAK93 is not equipped.
LEDs are located on the faceplate of the NTAK09 and NTBK50 cards. The
DCH LED is dual-color (red and green), with states represented as follows:
