Overview
Host interface bus
Cards based on the IPE bus use a built-in microcontroller. The IPE
microcontroller is used for the following:
•
to perform local diagnostics (self-test)
•
to configure the card according to instructions issued by the system
processor
•
to report back to the system processor information such as card
identification (type, vintage, and serial number), firmware version, and
programmed configuration status.
Table 7
Differences between IPE parameters
Parameter
IPE
Card Dimensions
31.75 x 25.4 x 2.2 cm. (12.5 x10.0 x 0.875 in.)
Network Interface
DS-30X Loops
Communication Interface
card LAN Link
Microcontroller
8031
Peripheral Interface card
NT8D01 Controller card
Network Interface card
NT8D04 Superloop Network card
Modules
NT8D37 IPE module
Intelligent Peripheral Equipment
IPE trunk cards all share a similar architecture.
IPE trunk card architecture" (page 49)
shows a typical IPE trunk card
architecture. The various trunk cards differ only in the number and types of
trunk interface units.
