NTVQ01xx Media Card
Contents
This section contains information on the following topics:
“Physical description” (page 981)
“Hardware architecture” (page 982)
“Functional description” (page 984)
Survivability
Physical description
The Media Card replaces the ITG Pentium card and is available as an
8-port or 32-port card.
You can install this card in slots 1 through 4 in the Media Gateway or slots
7 through 10 in the Media Gateway Expansion.
Note: Up to four Media Cards can be installed in each Media Gateway
and Media Gateway Expansion.
An NTVQ01xx Media Card is shown in Figure 282 "NTVQ01xx Media
Card" (page 982) .
