270
NT5D33 and NT5D34 Lineside E1 Interface cards
Table 101
LEI card - Switch 1 dip switch settings (cont’d.)
Characteristic
Selection
Switch
Position
Switch
Setting
Factory
Default
Card type for ringer
allocation
XTI = 19
XMLC = 18
7
7
ON
OFF
OFF
E1 signaling
See
8
OFF
OFF
When dip switch #1, positions 2 and 8 are set to "Table," AB Bits are
configured by the user through the Set Mode MMI command (see
). Otherwise, the signaling scheme selected by dip
switch 1, positions 2 and 8 are used.
Table 102
LEI card - signaling-type dip switch settings
Switch #1
Characteristic
Selection
Position 2
Position 8
Loop start
OFF
OFF
Ground start
ON
OFF
Australian P2
OFF
ON
Signaling Type
Table
ON
ON
Table 103
LEI card - XPEC address dip switch settings (Switch S1, positions 3-6)
XPEC
Address
S1 Switch
Position 3
S1 Switch
Position 4
S1 Switch
Position 5
S1 Switch
Position 6
00
OFF
OFF
OFF
OFF
01
ON
OFF
OFF
OFF
02
OFF
ON
OFF
OFF
03
ON
ON
OFF
OFF
04
OFF
OFF
ON
OFF
05
ON
OFF
ON
OFF
06
OFF
ON
ON
OFF
07
ON
ON
ON
OFF
08
OFF
OFF
OFF
ON
09
ON
OFF
OFF
ON
10
OFF
ON
OFF
ON
