NT5D33 and NT5D34 Lineside E1 Interface cards
Table 105
ELEI card - E1 Switch 2 (S2) dip switch settings
Characteristic
Selection
Switch
Position
Switch
Setting
Factory
Default
E1 framing
CRC-4 Disabled
CRC-4 Enabled
1
ON
OFF
ON
E1 coding
AMI
HDB3
2
ON
OFF
OFF
NOT USED
leave ON
3
ON
ON
NOT USED
leave ON
4
OFF
OFF
Mode
LEI Mode
ELEI Mode
5
OFF
ON
OFF
Line processing on E1 link
failure
On-hook
Off-hook
6
ON
OFF
OFF
Daisy-chaining to MMI
YES
NO
7
ON
OFF
OFF
MMI master or slave
Master
Slave
8
ON
OFF
ON
After the card has been installed, display the dip switch settings using
the MMI command Display Configuration (D C). See
maintenance interface software” (page 284)
for details on this and the rest
of the available MMI commands.
Installation
Because of the wiring in some of the system modules and cabinets, the
LEI only works in certain card slot pairs. These restrictions depend on
the type of module or cabinet. In all other modules or cabinets where the
conditions listed below do not exist, the LEI works in any two adjacent card
slots:
•
In the NTAK12 Small Remote IPE Expansion Cabinet only card slots
10-15 are available.
•
In the NT8D37 IPE module, if the 25-pair I/O connectors are partially
split between adjacent IPE card slots, the LEI works only in card slots
where Unit 0 of the motherboard card slot appear on the first pair of
the 25-pair I/O connector.
