Architecture 887
Table 382
Settings for the DCHI dip switch (SW1)
Switch Function On Off
S1-1 — — —
S1-2 F/W Mode DPNSS DCHI
Card-LAN interface
A Dual Port UART handles the functions of the serial ports for the
Card-LAN serial link test port interface. The test interface is an
asynchronous 4800 bps 8 bit connected to port A of the UART. The
card-LAN interface is an asynchronous 19.2 kbps 9 bit start/stop
connected to port B of the UART.
The connection to the test port is available at the backplane/MDF
connector.
The signals at this port conform to the EIA RS-232C standard.
A Dual Port UART handles the functions of the serial ports for the
Card-LAN serial link test port interface. The test interface is an
asynchronous 4800 bps 8 bit connected to port A of the UART. The
card-LAN interface is an asynchronous 19.2 kbps 9 bit start/stop
connected to port B of the UART.
The connection to the test port is available at the backplane/MDF
connector.
The signals at this port conform to the EIA RS-232C standard.
A Dual Port UART handles the functions of the serial ports for the
Card-LAN serial link test port interface. The test interface is an
asynchronous 4800 bps 8 bit connected to port A of the UART. The
card-LAN interface is an asynchronous 19.2 kbps 9 bit start/stop
connected to port B of the UART.
The connection to the test port is available at the backplane/MDF
connector.
The signals at this port conform to the EIA RS-232C standard.
