Connector pin assignments 697
Table 272
E and M Trunk card - backplane pinouts for 4-wire modes (cont’d.)
4-wire Type I Mode 4-wire Type II Mode
Trunk
Number
Pin Signal Pin Signal Pin Signal Pin Signal
16B TA 16A TB 16B TA 16A TB
17B RA 17A RB 17B RA 17A RB
18B E 18A M 18B EA 18A EB
1
19B ECG 19A ESCG 19B MA 19A MB
62B TA 62A TB 62B TA 62A TB
63B RA 63A RB 63B RA 63A RB
64B E 64A M 64B EA 64A EB
2
65B ECG 65A ESCG 65B MA 65A MB
66B TA 66A TB 66B TA 66A TB
67B RA 67A RB 67B RA 67A RB
68B E 68A M 68B EA 68A EB
3
69B ECG 69A ESCG 69B MA 69A MB
The E and M Trunk card brings the four analog trunks to the IPE
backplane through a 160-pin connector shroud. The backplane is cabled
to the I/O panel on the rear of the module, which is then connected to the
Main Distribution Frame (MDF) by 25-pair cables.
Telephone trunks connect to the E and M Trunk card at the MDF using a
wiring plan similar to that used for line cards.
