Connector pin assignments
131
Connector pin assignments
The OPS analog line card brings the eight analog telephone lines to the
IPE backplane through a 160-pin connector shroud. The backplane is
cabled to the input/output (I/O) panel on the rear of the module, which is
then connected to the Main Distribution Frame (MDF) by 25-pair cables.
Telephone lines from station equipment cross connect to the OPS analog
line card at the MDF using a wiring plan similar to that used for trunk
cards. A typical connection example is shown in
line card - typical cross connection example" (page 132)
, and a list of the
connections to the analog line card is shown in
line card - backplane pinouts" (page 131)
. See Communication Server
1000M and Meridian 1 Large System Installation and Configuration
(NN43021-310) for more detailed I/O panel connector information and wire
assignments for each tip/ring pair.
Table 56
OPS analog line card - backplane pinouts
Backplane
Connector
Pin
Signal
Backplane
Connector
Pin
Signal
12A
Unit 0, Ring
12B
Unit 0, Tip
13A
Unit 1, Ring
13B
Unit 1, Tip
14A
Unit 2, Ring
14B
Unit 2, Tip
15A
Unit 3, Ring
15B
Unit 3, Tip
16A
Unit 4, Ring
16B
Unit 4, Tip
17A
Unit 5, Ring
17B
Unit 5, Tip
18A
Unit 6, Ring
18B
Unit 6, Tip
19A
Unit 7, Ring
19B
Unit 7, Tip
The OPS analog line card brings the eight analog telephone lines to the
IPE backplane through a 160-pin connector shroud. The backplane is
cabled to the input/output (I/O) panel on the rear of the module, which is
then connected to the Main Distribution Frame (MDF) by 25-pair cables.
