Tone and digit switch cards
77
(the TDS/MFS loop is the even loop of the conference/TDS loop
pair)
Note: The conference/TDS card is not enabled automatically
when it is inserted. You must enable the card with the
command ENLX. (This command is used in LD 34 and LD 46
to address even loops and in LD 38 to address odd loops.)
Enabling the loops with the command ENLL does not enable
the hardware for the card.
For other than an NT8D17 Conference/TDS card, enter:
ENLL
loop
4
Test the TDS loop:
TDS loop
If the system response is other than OK, see Software
Input/Output Reference — Administration (NN43001-611) to
analyze the messages.
5
End the session in LD 34:
****
6
Using a maintenance telephone, log into the system.
See "Communicating with the Meridian 1" in the Software
Input/Output Reference — Administration (NN43001-611) for
details on accessing the system using a maintenance telephone.
7
From the maintenance telephone, enter:
LD#34##
To test outpulsers and channels for the TDS loop, see
for a sample of the input
commands used with the maintenance telephone. See Software
Input/Output Reference — Administration (NN43001-611) for all
tones that can be tested.
8
Exit LD 34 from the maintenance telephone:
****
--End--
Table 12
TDS tone tests
Input command
Dial pad
equivalent
Description
BSY#loop##
279#loop##
Provides busy tone from TDS loop specified.
C##
2##
Removes any active tone.
DIA#loop##
342#loop##
Provides dial tone from TDS loop specified.
OVF#loop##
683#loop##
Provides overflow tone from TDS loop specified.
