Nortel Networks 1000 User Manual
Page 151
151
.
NT4N39AA CP Pentium IV Card
Contents
This section contains information on the following topics:
“Physical description” (page 151)
“Functional description” (page 154)
“Front panel connector pin assignments” (page 155)
Introduction
The NT4N39AA Call Processor Pentium IV (CP PIV) Large System
processor card was introduced in CS 1000 Release 4.5. It features the
following:
•
a PCI-based design that is compatible with current CP PII architecture
•
an Intel Pentium processor
•
two CompactFlash (CF) sockets (one on-board and one hot-swappable
on the faceplate). The on-board CF is referred to as the Fixed Media
Disk (FMD), and the faceplate CF is referred to as the Removable
Media Disk (RMD). See
Figure 25 "CP PIV card (front)" (page 153)
and
Figure 26 "CP PIV card (side)" (page 154)
•
512 MBytes of Double Data Rate (DDR) memory
Physical description
The NT4N39AA card measures 23 cm by 16 cm (9,2 in. by 6.3 in.). See
Figure 25 "CP PIV card (front)" (page 153)
and
.
Nortel Communication Server 1000
Circuit Card Reference
NN43001-311
02.06
Standard
27 August 2008
Copyright © 2003-2008 Nortel Networks
.
