Pinout Tables
MPC5200B Users Guide, Rev. 1
Freescale Semiconductor 2-41
Pin PSC3_5 Ball A06
GPIO hi - z LP_CS_7
USB2 hi - z USB2_RXN
USB Receive Positive
UART3 hi - z LP_CS_7
UART3e hi - z LP_CS_7
CODEC3 hi - z LP_CS_7
CODEC3_w/MCLK hi - z CODEC3_w/MCLK_MCLK
CODEC Clock
SPI hi - z LP_CS_7
UART3, SPI hi - z LP_CS_7
UART3e,SPI hi - z LP_CS_7
CODEC3, SPI hi - z LP_CS_7
Pin PSC3_6 Ball C05
GPIO hi - z GPIO
Simple General Purpose I/O
USB2 hi - z USB2_PRTPWR
USB Port Power
UART3 hi - z GPIO
Simple General Purpose I/O
UART3e hi - z GPIO_
Simple General Purpose I/O
CODEC3 hi - z GPIO
Simple General Purpose I/O
CODEC3_w/MCLK hi - z LP_CS_7
SPI hi - z SPI_MOSI
SPI_Master Out Slave In
UART3, SPI hi - z SPI_MOSI
SPI_Master Out Slave In
UART3e, SPI hi - z SPI_MOSI
SPI_Master Out Slave In
CODEC3, SPI hi - z SPI_MOSI
SPI_Master Out Slave In
Table 2-15. PSC3 Functions by Pin (continued)
PIN / BALL NUMBER Function
Reset
Value
Description
