MPC5200B Users Guide, Rev. 1
15-28
Freescale Semiconductor
PSC Registers—MBAR + 0x2000, 0x2200, 0x2400, 0x2600, 0x2800, 0x2C00
15.2.19
Input Port Register (0x34)
—
IP
This read-only IP register shows the current state of the input ports.
Table 15-38. Interrupt Vector Register (0x30) for all Modes
msb 0
1
2
3
4
5
6
7 lsb
R
IVR[0:7]
W
RESET:
0
0
0
0
0
0
0
0
Bit
Name
Description
0:7
IVR
Interrupt Vector— Not applicable for MPC5200.
Table 15-39. Input Port Register (0x34) for UART/SIR/MIR/FIR Modes
msb 0
1
2
3
4
5
6
7 lsb
R
Reserved
DCD
CTS
W
Reserved
RESET:
1
1
1
1
1
1
0
0
Table 15-40. Input Port Register (0x34) for Codec Mode
msb 0
1
2
3
4
5
6
7 lsb
R
Reserved
TGL
Reserved
DCD
CTS
W
Reserved
RESET:
1
0
1
1
1
1
0
0
Table 15-41. Input Port Register (0x34) for AC97 Mode
msb 0
1
2
3
4
5
6
7 lsb
R
LPWR
TGL
Reserved
DCD
CTS
W
Reserved
RESET:
1
1
1
1
1
1
0
0
Bit
Name
Description
0
LPWR
AC97—Low power mode in AC97 mode
0 = Codec is in low power mode.
1 = Usual operation.
other Modes—Reserved
1
TGL
AC97 / Codec—Test usage. Toggle by FrameSync.
other Modes—Reserved
2:5
—
Reserved
