Pinout Tables
MPC5200B Users Guide, Rev. 1
Freescale Semiconductor 2-59
Pin ETH_12 Ball M02
GPIO hi - z
USB2 hi - z
ETH7 Wire hi - z ETH_RXD0
Ethernet Receive Data Input
ETH7 Wire / USB2 hi - z ETH_RXD0
Ethernet Receive Data Input
ETH18 Wire w/o MD hi - z ETH_RXD0
Ethernet Receive Data Input
ETH18 Wire w/ MD hi - z ETH_RXD0
Ethernet Receive Data Input
EHT7 Wire, UART4e, J1850 hi - z ETH_RXD0
Ethernet Receive Data Input
ETH7 Wire, J1850 hi - z ETH_RXD0
Ethernet Receive Data Input
UART_4, UART5e, J1850 hi - z UART5e_RXD
Uart Receive Data
UART5e, J1850 hi - z UART5e_RXD
Uart Receive Data
J1850 hi - z ----
Pin ETH_13 Ball M01
GPIO hi - z INTERRUPT
USB2 hi - z USB_2_RECEIVE DIFFERENTIAL
ETH7 Wire hi - z INTERRUPT
ETH7 Wire / USB2 hi - z USB_2_RECEIVE DIFFERENTIAL
ETH18 Wire w/o MD hi - z ETH_RXD1
Ethernet Receive Data Input
ETH18 Wire w/ MD hi - z ETH_RXD1
Ethernet Receive Data Input
EHT7 Wire, UART4e, J1850 hi - z J1850_RX
J1850 Receive Data
ETH7 Wire, J1850 hi - z J1850_RX
J1850 Receive Data
UART_4, UART5e, J1850 hi - z J1850_RX
J1850 Receive Data
UART5e, J1850 hi - z J1850_RX
J1850 Receive Data
J1850 hi - z J1850_RX
J1850 Receive Data
Table 2-21. Ethernet Input / Control Functions by Pin (continued)
PIN / BALL NUMBER Function
Reset
Value
Description
