Pinout Tables
MPC5200B Users Guide, Rev. 1
Freescale Semiconductor 2-63
Table 2-23. Timer Functions by Pin
PIN / BALL NUMBER Function
Reset
Value
Description
Pin TIMER_0 Ball Y20
TIMER hi - z TIMER_0
GPIO hi - z GPIO
Simple General Purpose I/O
ATA CHIP SELECTS hi - z ATA_CS0
ATA Chip Select 0
CAN2 hi - z CAN2_TX
CAN 2 Transmit Data
SPI hi - z GPIO
Simple General Purpose I/O
CAN2 / SPI hi - z CAN2_TX
CAN 2 Transmit Data
Pin TIMER_1 Ball V18
TIMER hi - z TIMER_1
GPIO hi - z GPIO
Simple General Purpose I/O
ATA CHIP SELECTS hi - z ATA_CS0
ATA Chip Select 1
CAN2 hi - z CAN2_RX
CAN 2 Receive Data
SPI hi - z GPIO
Simple General Purpose I/O
CAN2 / SPI hi - z CAN2_RX
CAN 2 Receive Data
Pin TIMER_2 Ball D03
TIMER hi - z TIMER_2
GPIO hi - z GPIO
Simple General Purpose I/O
ATA CHIP SELECTS hi - z GPIO
Simple General Purpose I/O
CAN2 hi - z GPIO
Simple General Purpose I/O
SPI hi - z SPI _MOSI
SPI Master Out Slave In
CAN2 / SPI hi - z SPI MOSI
SPI Master Out Slave In
