Freescale Semiconductor MPC5200B - Manual (Page 85)

MPC5200B Users Guide, Rev. 1
2-40 Freescale Semiconductor
Pinout Tables
Pin PSC3_3 Ball C06
GPIO hi - z GPIO
Simple General Purpose I/O
USB2 hi - z USB2_RXD
USB Receive Data
UART3 hi - z UART3_CTS
Uart Clear To Send
UART3e hi - z UART3e_CTS
Uart Clear To Send
CODEC3 hi - z CODEC3_FRAME
CODEC Frame Sync
CODEC3_w/MCLK hi - z CODEC3_w/MCLK_FRAME
CODEC Frame Sync
SPI hi - z GPIO
Simple General Purpose I/O
UART3, SPI hi - z UART3_CTS
Uart Clear to Send
UART3e, SPI hi - z UART3e_CTS
Uart Clear To Send
CODEC3, SPI hi - z CODEC3_FRAME
CODEC Frame Sync
Pin PSC3_4 Ball B06
GPIO hi - z LP_CS_6
USB2 hi - z USB2_RXP
USB Receive Positive
UART3 hi - z LP_CS_6
UART3e hi - z UART3e_DCD
UART3e Carrier Detect
CODEC3 hi - z LP_CS_6
CODEC3_w/MCLK hi - z LP_CS_6
SPI hi - z LP_CS_6
UART3, SPI hi - z LP_CS_6
UART3e,SPI hi - z UART3e_DCD
UART3e Carrier Detect
CODEC3, SPI hi - z LP_CS_6
Table 2-15. PSC3 Functions by Pin (continued)
PIN / BALL NUMBER Function
Reset
Value
Description
