CDM Registers
MPC5200B Users Guide, Rev. 1
Freescale Semiconductor
5-15
NOTE
The clock ratio should only be changed if no module, which is clocked by the IPB and/or PCI clock,
is currently running. Suggestion is to change the clock ratio during the boot time only.
5.5.5
CDM 48MHz Fractional Divider Configuration Register—MBAR + 0x0210
The CDM 48MHz Fractional Divider Configuration Register contains the control bits used in the 48MHz fractional divider.
Bit
Name
Description
0–6
—
Reserved for future use. Write 0.
7
ddr_mode
SDRAM Controller DDR memory mode, read-only.
bit=0:SDRAM Controller configured for SDR SDRAM (single data rate)
bit=1:SDRAM Controller configured for DDR SDRAM (double data rate)
This register location is a read-only status bit; write 0. The controlling register is in the
SDRAM Controller register map. In the CDM this bit determines the frequency and phase
of memory read clock.
8–14
—
Reserved for future use. Write 0.
15
xlb_clk_sel
XLB Clock Frequency
bit=0:XLB CLK = f
system
/4
bit=1:XLB CLK = f
system
/8
This register location is a read-only status bit. The controlling register is the POR
Configuration register - cdm configuration register [26].
16–22
—
Reserved for future use. Write 0.
23
ipb_clk_sel
IPB Clock Select
bit=0:IPB CLK = XLB_CLK
bit=1:IPB CLK = XLB_CLK/2
24–29
—
Reserved for future use. Write 0.
30-31
pci_clk_sel
PCI Clock Select
00–PCI_CLK = IPB_CLK
01–PCI_CLK = IPB_CLK/2
10–PCI_CLK = XLB_CLK/4
See also
.
Table 5-12. CDM 48MHz Fractional Divider Configuration Register
msb 0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
R
Reserved
Write 0
e
x
t_usb
_
sync_en
e
x
t_usb
_
48mhz_en
e
x
t_irda_
48mhz_en
Reserved
Write 0
fd_en
W
RESET:
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31 lsb
R
Rsr
v
d
Wr
it
e 0
cfgd_p3_cnt
Rsr
v
d
Wr
it
e 0
cfgd_p2_cntt
Rsr
v
d
Wr
it
e 0
cfgd_p1_cnt
Rsr
v
d
Wr
it
e 0
cfgd_p0_cnt
W
RESET:
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
