Host Control (HC) Operational Registers
MPC5200B Users Guide, Rev. 1
Freescale Semiconductor 12-11
12.4.2.6 USB HC Interrupt Disable Register—MBAR + 0x1014
Each disable bit in the HC Interrupt Disable register corresponds to an associated interrupt bit in the HcInterruptStatus register. The
HcInterruptDisable register is coupled with the HcInterruptEnable register. Thus, writing a ‘1’ to a bit in this register clears the corresponding
bit in the HcInterruptEnable register, whereas writing a ‘0’ to a bit in this register leaves the corresponding bit in the HcInterruptEnable register
unchanged. On read, the current value of the HcInterruptEnable register is returned.
Bits Name Description
0 MIE Master Interrupt Enable—used by HCD.
0 - writing to this bit is ignored by HC.
1 - writing to this bit enables interrupt generation, due to events specified in other bits of
this register.
1 OC OwnershipChange
0 - writing to this bit is ignored by HC.
1 - writing to this bit enables interrupt generation, due to ownership.
2:24 — Reserved
25 RHSC RootHubStatusChange
0 - Ignore
1 - Enable interrupt generation due to root hub status change.
26 FNO FrameNumberOverflow
0 - Ignore
1- Enable interrupt generation due to frame number overflow.
27 UE UnrecoverableError
0 - Ignore
1 - Enable interrupt generation due to unrecoverable error.
28 RD ResumeDetected
0 - Ignore
1 - Enable interrupt generation due to resume detect.
29 SF StartofFrame
0 - Ignore
1 - Enable interrupt generation due to start of frame.
30 WDH WritebackDoneHead
0 - Ignore
1 - Enable interrupt generation due to HcDoneHead writeback.
31 SO SchedulingOverrun
0 - Ignore
1 - Enable interrupt generation due to scheduling overrun.
Table 12-6. USB HC Interrupt Disable Register
msb 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
R MIE OC Reserved
W
RESET: 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
