Pinout Tables
MPC5200B Users Guide, Rev. 1
Freescale Semiconductor 2-33
Pin PSC1_3 Ball B10
GPIO hi - z GPIO
Simple General Purpose I/O
AC97_1 hi - z AC97_1_BITCLK
AC97 Bit Clock
UART1 hi - z UART1_CTS
UART Clear To Send
UART1e hi - z UART1e_CTS
UARTe Clear To Send
CODEC1 hi - z CODEC1_CLK
CODEC Bit Clock
CODEC1_w/MCLK hi - z CODEC1_w/MCLK_CLK
CODEC Bit Clock
Pin PSC1_4 Ball A10
GPIO hi - z GPIO
Simple General Purpose I/O with WAKE UP
AC97_1 hi - z AC97_1_RES
AC97 Reset
UART1 hi - z GPIO
Simple General Purpose I/O with WAKE UP
UART1e hi - z UART1e_DCD
UARTe Carrier Detect
CODEC1 hi - z CODEC1_FRAME
CODEC Frame Sync
CODEC1_w/MCLK hi - z CODEC1_w/MCLK_FRAME
CODEC Frame Sync
Table 2-10. PSC1 Functions by Pin (continued)
PIN / BALL NUMBER Function
Reset
Value
Description
