Pinout Tables
Pin EXT_AD_15 Ball U08
LocalPlus Bus multiplexed mode
Address Phase
8-Bit Data Phase
16-Bit Data Phase
32-Bit Data Phase
A15
logic 0
logic 0
D15
hi - z
LocalPlus Address Bit A15
logic 0
logic 0
LocalPlus Data Bit D15
LocalPlus non-mux
16-bit addr/16-bit data
24-bit addr/8-bit data
A15
A15
hi - z
LocalPlus Address Bit A15
LocalPlus Address Bit A15
LFLASH A15 hi - z Large Flash Address Bit A15
MOST Graphics D15 hi - z MOST Graphics Data Bit D15
ATA ATA_DATA_1
5 hi - z ATA Data Bit 15
PCI
Address Phase
8-Bit Data Phase
16-Bit Data Phase
32-Bit Data Phase
A15
logic 0
D15
D15
hi - z
PCI Address Bit A15
logic 0
PCI Data Bit D15
PCI Data Bit D15
Pin EXT_AD_14 Ball W09
LocalPlus Bus multiplexed mode
Address Phase
8-Bit Data Phase
16-Bit Data Phase
32-Bit Data Phase
A14
logic 0
logic 0
D14
hi - z
LocalPlus Address Bit A14
logic 0
logic 0
LocalPlus Data Bit D14
LocalPlus non-mux
16-bit addr/16-bit data
24-bit addr/8-bit data
A14
A14
hi - z
LocalPlus Address Bit A14
LocalPlus Address Bit A14
LFLASH A14 hi - z Large Flash Address Bit A14
MOST Graphics D14 hi - z MOST Graphics Data Bit D14
ATA ATA_DATA_1
4 hi - z ATA_DATA_14
PCI
Address Phase
8-Bit Data Phase
16-Bit Data Phase
32-Bit Data Phase
A14
logic 0
D14
D14
hi - z
PCI Address Bit A14
logic 0
PCI Data Bit D14
PCI Data Bit D14
Pin EXT_AD_13 Ball V08
LocalPlus Bus multiplexed mode
Address Phase
8-Bit Data Phase
16-Bit Data Phase
32-Bit Data Phase
A13
logic 0
logic 03
D13
hi - z
LocalPlus Address Bit A13
logic 0
logic 0
LocalPlus Data Bit D13
LocalPlus non-mux
16-bit addr/16-bit data
24-bit addr/8-bit data
A13
A13
hi - z
LocalPlus Address Bit A13
LocalPlus Address Bit A13
LFLASH A13 hi - z Large Flash Address Bit A13
MOST Graphics D13 hi - z MOST Graphics Data Bit D13
ATA ATA_DATA_1
3 hi - z ATA Data Bit D13
PCI
Address Phase
8-Bit Data Phase
16-Bit Data Phase
32-Bit Data Phase
A13
logic 0
D13
D13
hi - z
PCI Address Bit A13
logic 0
PCI Data Bit D13
PCI Data Bit D13
Table 2-5. LocalPlus Bus Address / Data Signals (continued)
PIN / BALL NUMBER Function
Reset
Value
Description
