General Purpose I/O (GPIO)
MPC5200B Users Guide, Rev. 1
Freescale Semiconductor
7-23
PSC1_0
UART1/AC971/CODEC1
No
No
PSC1_1
UART1/AC971/CODEC1
No
No
PSC1_2
UART1/AC971
No
No
PSC1_3
UART1/AC971/CODEC1
No
No
PSC1_4
UART1/AC971/CODEC1
Yes
Yes
PSC2_0
UART2/AC972/CODEC2/CAN1
No
No
PSC2_1
UART2/AC972/CODEC2/CAN1
No
No
PSC2_2
UART2/AC972/CAN2
No
No
PSC2_3
UART2/AC972/CODEC2/CAN2
No
No
GPIO_WKUP_1(PSC2_4)
UART2/AC972/CODEC2
Yes
Yes
GPIO_PSC3_0
USB2/CODEC3/UART3
No
No
GPIO_PSC3_1
USB2/CODEC3/UART3
No
No
GPIO_PSC3_2
USB2/CODEC3/UART3
No
No
GPIO_PSC3_3
USB2/CODEC3/UART3
No
No
GPIO_SINT_0(PSC3_4)
USB2/UART3
Yes
No
GPIO_SINT_1(PSC3_5)
USB2
Yes
No
GPIO_PSC3_6
USB2/SPI
No
No
GPIO_PSC3_7
USB2/SPI
No
No
GPIO_SINT_2(PSC3_8)
USB2/SPI
Yes
No
GPIO_WKUP_2(PSC3_9)
USB2/SPI
Yes
Yes
GPIO_USB_0
USB1 (OE)
No
No
GPIO_USB_1
USB1 (PORTPWR)/UART5 (TXD)
No
No
GPIO_USB_2
USB1 (SPEED)/UART5 (RTS)
No
No
GPIO_USB_3
USB1 (SUSPEND)/UART5 (CTS)
No
No
GPIO_SINT_3(USB)
USB1 (OvrCrnt)
Yes
No
GPIO_ETHO_0(out only)
Ethernet
No
No
GPIO_ETHO_1(out only)
Ethernet/UART5
No
No
GPIO_ETHO_2(out only)
Ethernet/USB2/UART5
No
No
GPIO_ETHO_3(out only)
Ethernet/USB2/UART4
No
No
GPIO_ETHO_4(out only)
Ethernet/USB2/J1850
No
No
GPIO_ETHO_5(out only)
Ethernet/USB2/UART4
No
No
GPIO_ETHO_6(out only)
Ethernet/USB2
No
No
GPIO_ETHO_7(out only)
Ethernet/USB2
No
No
GPIO_ETHI_0
Ethernet/UART5
No
No
GPIO_ETHI_1
Ethernet/UART5
No
No
Table 7-20. GPIO Pin List (continued)
GPIO PIN
Alternate Functionality
Interrupt
WakeUp
