Mclk = mclkdiv [8:0] + 1 f – Freescale Semiconductor MPC5200B User Manual
Page 536
PSC Registers—MBAR + 0x2000, 0x2200, 0x2400, 0x2600, 0x2800, 0x2C00
MPC5200B Users Guide, Rev. 1
Freescale Semiconductor
15-25
The Mclk frequency is generated in the Clock Distribution Module (CDM) by dividing down the f
system
frequency as follows:
There is a separate cdm_pscX_bitclk_config register in the CDM for each of PSC1,2,3 and 6, which are the PSCs available for use in Codec
modes. These cdm_pscX_bitclk_config registers are further described in the CDM
Section 5.5.11, PSC1 Mclock Config Register—MBAR +
Section 5.5.14, PSC6 (IrDA) Mclock Config Register—MBAR + 0x0234.
Bit
Name
Description
0:7
FrameSyncDiv
Codec—Frame Sync Divider
FrameSync is generated internally by dividing down the Bit Clock. The FrameSyncDiv
defines the number of Bit clock cycles between two active frame edges:
FrameSync Length = FrameSyncDiv[0:7] + 1
For more information see also
Section 15.3.2.3, Transmitting and Receiving in “Soft
Codec / SPI—delay before SCK (DSCKL)
When the PSC is in SPI mode (
[SPI] = 1), the FrameSyncDiv divider is used to
determine the length of time the PSC delays after SS goes low/active before the first
SCK transition of the serial transfer. This is a feature that exists in a QSPI. The following
equation determines the actual delay before SCK:
other Modes—Reserved
Note: The value 0x00 stops this counter and disables the clock generator.
7:23
BitClkDiv
Codec—Bit Clock Divider
Bit clock is generated internally by dividing down the Mclk frequency as follows:
Codec SPI—Baud Rate
SCK is generated internally by dividing down the Mclk frequency as follows:
MIR / FIR—Irda clock
IrdaClk is generated internally by dividing down the Mclk frequency as follows:
other Modes—Reserved
Note: The value 0x00 stops this counter and disables the clock generator.
DSCKL delay =
Mclk Frequency
FrameSyncDiv[0:7] + 1)
BitClk frequency =
Mclk Frequency
BitClkDiv[0:15] + 1
SCK frequency =
Mclk Frequency
BitClkDiv[0:15] + 1
IrdaClk frequency =
Mclk Frequency
BitClkDiv[0:15] + 1
Mclk =
MclkDiv [8:0] + 1
f
system
