Pinout Tables
V13
EXT_AD_0
Y10
EXT_AD_10
V14
LP_ALE
Y11
EXT_AD_7
V15
LP_CS2
Y12
EXT_AD_3
V16
LP_CS5
Y13
LP_TS
V17
ATA_DRQ
Y14
LP_CS1
V18
TIMER_1
Y15
LP_CS4
V19
I2C_0
Y16
ATA_ISOLATION
V20
I2C_2
Y17
ATA_IOR
W01
EXT_AD_29
Y18
ATA_DACK
W02
EXT_AD_25
Y19
ATA_INTRQ
W03
EXT_AD_23
Y20
TIMER_0
W04
EXT_AD_16
W05
PCI_TRDY
W06
PCI_CBE_2
W07
PCI_DEVSEL
W08
PCI_SERR
W09
EXT_AD_14
W10
PCI_CBE_0
W11
EXT_AD_8
W12
EXT_AD_5
W13
EXT_AD_1
W14
LP_CS0
W15
LP_CS3
W16
LP_RW
W17
ATA_IOW
W18
ATA_IOCHRDY
W19
I2C_1
W20
I2C_3
Y01
EXT_AD_27
Y02
PCI_CBE_3
Y03
EXT_AD_21
Table 2-1. Signals by Ball/Pin (continued)
Ball/Pin
Pin Name
Ball/Pin
Pin Name
