MPC5200B Users Guide, Rev. 1
2-2 Freescale Semiconductor
Overview
Figure 2-1. 272-Pin PBGA Pin Detail
Table 2-1 gives a list of MPC5200B I/O signals sorted by package ball name. Table 2-2 gives the same list sorted by signal name.
Many signal pins can have multiple functions depending on internal register settings. These additional functions are described in Table 2-3
through Table 2-31.
K
J
H
G
F
E
D
C
B
A
Y
W
V
U
T
R
P
N
M
L
10 1 2 3 4 5 6 7 8 9 11 13 14 15 16 17 18 19 20 12
View Looking at Pins (Balls)
A1 signal: A20 signal:
test_mode_1 mem_dqm_2
Note: Table 2-1 and Table 2-2 give the signals on each pin/ball.
Y20 signal:
timer0
Y1 signal:
ext_ad_27
