Pinout Tables
MPC5200B Users Guide, Rev. 1
Freescale Semiconductor 2-11
MEM_MA_10 B17 MEM_MDQS_0 N20
MEM_MA_11 E20 MEM_MDQS_1 H20
MEM_MA_12 F19 MEM_MDQS_2 D18
MEM_MBA_0 C18 MEM_MDQS_3 L18
MEM_CLK G19 PSC3_5 A06
MEM_CLK G20 PSC3_6 C05
MEM_RAS A18 PSC3_7 B05
MEM_WE A19 PSC3_8 A05
PCI_CBE_0 W10 PSC3_9 C04
PCI_CBE_1 Y08 RTC_XTAL_IN C02
PCI_CBE_2 W06 RTC_XTAL_OUT C01
PCI_CBE_3 Y02 SRESET A14
PCI_CLOCK T01 SYS_PLL_AVDD B14
PCI_DEVSEL W07 SYS_PLL_AVSS C14
PCI_FRAME V05 SYS_PLL_TPA B15
PCI_GNT R04 SYS_XTAL_IN A15
PCI_IDSEL U02 SYS_XTAL_OUT D14
PCI_IRDY Y06 TEST_MODE_0 B02
PCI_PAR V07 TEST_MODE_1 A01
PCI_PERR Y07 TEST_SEL_0 B01
PCI_REQ U01 TEST_SEL_1 C03
PCI_RESET R02 TIMER_0 Y20
PCI_SERR W08 TIMER_1 V18
PCI_STOP V06 TIMER_2 D03
PCI_TRDY W05 TIMER_3 D02
PORRESET A13 TIMER_4 D01
PSC1_0 B11 TIMER_5 E03
PSC1_1 A11 TIMER_6 E02
PSC1_2 C10 TIMER_7 E01
PSC1_3 B10 USB_0 H01
PSC1_4 A10 USB_1 H02
PSC2_0 C09 USB_2 H03
PSC2_1 B09 USB_3 G01
PSC2_2 A09 USB_4 G02
PSC2_3 B08 USB_5 G03
Table 2-2. Signals by Signal Name (continued)
Signal Name Ball/Pin Signal Name Ball/Pin
