Pinout Tables
MPC5200B Users Guide, Rev. 1
Freescale Semiconductor 2-61
Pin ETH_16 Ball L02
GPIO hi - z INTERRUPT
USB2 hi - z USB_2_OVRCNT
USB Over Current
ETH7 Wire hi - z INTERRUPT
ETH7 Wire / USB2 hi - z USB_2_OVRCNT
USB Over Current
ETH18 Wire w/o MD hi - z ETH_RXERR
Ethernet Receive Error Input
ETH18 Wire w/ MD hi - z ETH_RXERR
Ethernet Receive Error Input
EHT7 Wire, UART4e, J1850 hi - z UART4e_DCD
Uart Carrier Detect
ETH7 Wire, J1850 hi - z INTERRUPT
UART_4, UART5e, J1850 hi - z INTERRUPT
UART5e, J1850 hi - z INTERRUPT
J1850 hi - z INTERRUPT
Pin ETH_17 Ball J04
GPIO hi - z GPIO
Simple General Purpose Output with WAKE UP
USB2 hi - z GPIO
Simple General Purpose Output with WAKE UP
ETH7 Wire hi - z GPIO
Simple General Purpose Output with WAKE UP
ETH7 Wire / USB2 hi - z GPIO
Simple General Purpose Output with WAKE UP
ETH18 Wire w/o MD hi - z ETH_CRS
Ethernet Carrier Sense Input
ETH18 Wire w/ MD hi - z ETH_CRS
Ethernet Carrier Sense Input
EHT7 Wire, UART4e, J1850 hi - z GPIO
Simple General Purpose Output with WAKE UP
ETH7 Wire, J1850 hi - z GPIO
Simple General Purpose Output with WAKE UP
UART_4, UART5e, J1850 hi - z GPIO
Simple General Purpose Output with WAKE UP
UART5e, J1850 hi - z GPIO
Simple General Purpose Output with WAKE UP
J1850 hi - z GPIO
Simple General Purpose Output with WAKE UP
Table 2-21. Ethernet Input / Control Functions by Pin (continued)
PIN / BALL NUMBER Function
Reset
Value
Description
